This seemingly simple goal – whilst also keeping an applicable price structure in order – was quite literally driving us in circles.
After years of trial and error, the conclusion was to copy our own The Silver Bullet OTL circuit , but with transistors in the output stage. Yet again this resulted in an EINSTEIN typical circuit which, outside of our own adoption, hasn’t seen much of an audience in the world of high-end audio. As in our OTL designs, the circuit is designed as fully balanced and thus is able to captivate with an incredible signal to noise ratio and the elimination of typical sound influencing circuit distortions. By choosing a high bias current design, excellent linearity is achieved with extreme bandwidth extension on both sides of the frequency spectrum. Dynamics aren’t compressed in any way and no matter the listening level, no audible compression level is heard, leaving you to hear every possible detail.
As with our OTL circuit, a differential amplifier is used in a cascade circuit. The input stage of the new The Poweramp, consists of double triodes, type EI PCC88, which produce extreme linearity. As in the OTL, this circuit utilizes the incoming signal to create an absolutely symmetrical – balanced – signal with the appropriate amplification level. This clever design enables us to use two identical power amplifier transistors in the output stage, with absolutely identical technical specifications, comparable to the power tubes in our The Silver Bullet OTL. The mass here is also “floating”, which in practice means no interference problems with ground loops that degrade the signal to noise ratio. Of course, as is typical with all EINSTEIN electronics, the volume relay is not in the signal path.
As with all other EINSTEIN circuits, a very advanced power supply is required to maintain stable power for our innovative circuits. Tremendous energy reserves and the decoupling and stabilization of all important supply voltages ensures this even in poor power conditions. Due to the excellent damping factor and the incredible power supply stability – even at the peak-to-peak impulses – our The Poweramp can drive almost any speaker without any problems. Obviously, great loudspeakers will benefit quite nicely from our newest amplifier.
With our new The Poweramp, we have thus reached our goal: realistic, incredibly resolved playback with natural dynamics and no compression. You are able to immerse yourself even deeper in your music, almost as if you were attending a live concert.
Specification
Fully balanced dual mono design
Extreme bandwidth
Outstanding channel separation
Exceptional signal to noise ratio, greater than 100dB
Variable input sensitivity for the proper preamp connection; not in the signal path thereby also optimally used in a bi-amped setup
Special power cord
Utilizes only identical transistors in the output stage, thus no crossover distortion
Channel separation of 85 dB or better
Distortion at 1 kHz less than 0,01%
Output power 90 watts / 8 ohms (140 watts / 4 ohms)
Damping factor greater than 250/8 Ohm
Weight 21 Kg
Dimensions (H x W x D) 17 cm x 43 cm x 41 cm
